| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | BOSHI |
| Certification: | CE SGS |
| Model Number: | BS-420 BS-520 BS-720 |
| Minimum Order Quantity: | One sets |
| Price: | 5000USD-18500USD per set |
| Packaging Details: | Standard three plywood wooden cases |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 300 sets per year |
| Key Words: | Automatic Frozen Beans Frozen Vegetable Frozen Food Packing Machine | Voltage: | 220V 50/60HZ 3KW |
|---|---|---|---|
| Key Selling Points: | For Frozen Product | Packaging Type: | Stand-up Pouch, Bags, Film, Foil, Pouch |
| Function: | Automatic Packaging System | Driven Type: | Electrical And Pneumatic |
| Core Components: | Motor, PLC, Servo Driver Servo Motor Etc | Packing Style: | Pillow Bag |
| Packing Speed: | 5-60 Bags/min | Dimension(L*W*H): | L 1350 * W 1000 * H 1400 Mm |
| Film Thickness: | 0.03-0.1mm | Machinery Test Report: | Provided |
| After Sales Service: | Video Technical Support, Online Support | ||
| High Light: | Vegetable Packing Machine Waterproof,Vegetable Packing Machine Dustproof,PLC Full Automatic Packing Machine |
||
Automatic Frozen Beans Frozen Vegetable Frozen Food Packing Machine
4. Full stainless steel machine frame, ensure the long service life.
5. Machine is design for waterproof and dustproof. Sutiable for different kinds of product.
6. Imported PLC control system, more stable and high efficiency.
It is suitable for frozen food, whole grains, puffed food, candy biscuits, agricultural dry goods,
preserved nuts, hardware and plastics, chemical particles, Chinese herbal medicine, seasoning sugar, etc.
Machine characteristic:
| Model | BS-420G |
| Film width | Max.420mm |
| Film thickness | 0.03-0.1mm |
| Bag width | 50-200 mm |
| Bag length | 50-300 mm |
| Packing speed | 10-70 bags/ min |
| Type of sealing | Pillow bag,3 or 4 side seal and gusset bag |
| Packing material | OPP/CPP, OPP/CE,PET/PE etc. |
| Air consumption | 0.65 mpa |
| Gas consumption | 0.3 cubic meter/ min |
| Machine dimensions | 1080*1300*1400 mm |
| Machine weight | 600 kg |
| Multi-weigher | |
| Weighting and filling system | Head weighers |
| Weighting range | 10-3000g (Different product have different weighting range ) |
| Accuracy: | Bias:+-0.5g |
| Filling speed: | 65bags/min |
| Hoper volume | 1.6/2.5L/5L |
| Total power: | 1.0kw |
| Weight |
380KG
|
