| Place of Origin: | China |
|---|---|
| Brand Name: | BOSHI Powder packing machine |
| Certification: | CE, ROSH, SGS |
| Model Number: | BS-420P BS-520P |
| Minimum Order Quantity: | 1set |
| Price: | 8800-10800 USD |
| Packaging Details: | 3 plywood wooden box packaging |
| Delivery Time: | 15-30 working days |
| Supply Ability: | 50 sets/ month |
| Advantages :: | Wide Application | Key Words:: | Automatic Powder Collar Packing Machine Wheat Flour Powder Packing Machine |
|---|---|---|---|
| Film Materils :: | Laminated Films And PE Film | Bag Type :: | Pillow Bag And Gusseted Pillow Bag |
| Machine Speed Range:: | 5-60 Bags/ Min | Bag Width:: | 50-200 Mm |
| Bag Length:: | 50-300 Mm | Function:: | FILLING, Wrapping, Labeling, Sealing, Date Printing |
| Driven Type:: | Pneumatic Pillow Bag Or Gusset Bag Or Quad Side Seal | Voltage:: | 220/380v |
| Dimension(L*W*H):: | L 1320 * W 920 * H 1392 Mm | ||
| High Light: | 60bags/min Collar Packing Machine,Wheat Flour Powder Packing Machine,5bags/min Collar Packing Machine |
||
1. Fast speed, high precision, it adopts the servo drive metering.
2. The powders are delivery and measured in sealing, so it does not bring any dust.
3. The whole packing system is totally sealing, avoid powder leakage.
4. All set of machine is made of stainless steel 304, ensure long service life.
5. The machine can make pillow bag, gusseted pillow bag, stand up pouch.
|
Model
|
BS-420P |
|
Film width
|
Max.420mm |
| Film thickness | 0.03-0.1mm |
| Bag width | 50-200 mm |
| Bag length | 50-300 mm |
| Packing speed | 10-70 bags/ min |
| Type of sealing | Pillow bag,3 or 4 side seal and gusset bag |
| Packing material | OPP/CPP, OPP/CE,PET/PE etc. |
| Air consumption | 0.65 mpa |
| Gas consumption | 0.3 cubic meter/ min |
| Machine dimensions | 1080*1300*1400 mm |
| Machine weight | 600 kg |
| Auger filler | |
| Weighting and filling system | Auger screw |
| Weighting range | 10-5000g (Different product have different weighting range ) |
| Accuracy: | Volume<100g.Bias:0.5-1gVolume:100-5000g.Bias:0.5%-1% |
| Filling speed: | 10-60 bags/min |
| Filler hoper volume | 50 L |
| Total power: | 1.5 kw |
| Weight |
200KG
|
Machine advantages:
Applications:
Suitable for filling and packing varieties of powders, such as milk powder, coffee powder, fruit powder,cocoa powder, grain powder, wheat flour, spice, flour,and etc.
