| Place of Origin: | China |
|---|---|
| Brand Name: | BOSHI Powder packing machine |
| Certification: | CE, ROSH, SGS |
| Model Number: | BS-420P BS-520P |
| Minimum Order Quantity: | 1set |
| Price: | 8800-10800 USD |
| Packaging Details: | 3 plywood wooden box packaging |
| Delivery Time: | 15-30 working days |
| Supply Ability: | 50 sets/ month |
| Key Words:: | Automatic Sugar Powder Curry Powder Spice Powder Coffee Powder Packing Machine | Film Materils :: | Laminated Films, PE Film |
|---|---|---|---|
| Bag Type :: | Pillow Bag, Gusseted Bag | Machine Speed Range:: | 5-60 Bags/ Min |
| Bag Width:: | 50-200 Mm | Bag Length:: | 50-300 Mm |
| Function:: | FILLING, Wrapping, Labeling, Sealing, Date Printing | Driven Type:: | Pneumatic Pillow Bag Or Gusset Bag Or Quad Side Seal |
| Voltage:: | 220/380v | Dimension(L*W*H):: | L 1320 * W 920 * H 1392 Mm |
| High Light: | Curry Powder Packing Machine,Coffee Powder Packing Machine 60 bags/ min,ROSH Sugar Powder Packing Machine |
||
1. Stable speed, high accuracy , it use servo drive metering.
2. Powder are delivery and weighting in sealing, so it won't bring any dust.
3. Servo and PLC control system, use world famous brand.
4. Human interface touch screen, easy to operate and maintance the machine.
5. High precise film location with servo film transport system, ensure the machine stable.
|
Model
|
BS-420P |
|
Film width
|
Max.420mm |
| Film thickness | 0.03-0.1mm |
| Bag width | 50-200 mm |
| Bag length | 50-300 mm |
| Packing speed | 10-70 bags/ min |
| Type of sealing | Pillow bag,3 or 4 side seal and gusset bag |
| Packing material | OPP/CPP, OPP/CE,PET/PE etc. |
| Air consumption | 0.65 mpa |
| Gas consumption | 0.3 cubic meter/ min |
| Machine dimensions | 1080*1300*1400 mm |
| Machine weight | 600 kg |
| Auger filler | |
| Weighting and filling system | Auger screw |
| Weighting range | 10-5000g (Different product have different weighting range ) |
| Accuracy: | Volume<100g.Bias:0.5-1gVolume:100-5000g.Bias:0.5%-1% |
| Filling speed: | 10-60 bags/min |
| Filler hoper volume | 50 L |
| Total power: | 1.5 kw |
| Weight |
200KG
|
Machine advantages:
Applications:
Suitable for filling and packing varieties of powders, such as milk powder, coffee powder, fruit powder,cocoa powder, grain powder, wheat flour, spice, flour,and etc.
