Detail Information

Key Words:	Automatic Corn Flakes Dried Mango Snack Pouch Packing Machine	Packing Style:	Standard Pillow Bag
Key Selling Points:	Automatic Form	Driven Type:	Electrical And Pneumatic
Function:	Wrapping, Labeling, Sealing, Date Printing	Packing Speed:	5-60 Bags/min
Dimension(LWH):	L 1350 * W 1000 * H 1400 Mm	Packaging Type:	Bags, Film, Foil
Voltage:	110v/220v/380v/440v	Film Thickness:	0.03-0.1mm
Machinery Test Report:	Provided	Core Components:	Motor, PLC, Servo Driver Etc
Warranty Of Core Components:	1 Year
High Light:	Dried Mango Snack Packing Machine , Snack Packing Machine Multifunctional , Automatic corn flakes packing machine

Product Description

Automatic Corn Flakes Dried Mango Snack Pouch Packing Machine

Main Features:

1. Strength of standard combination weigher : wide range of application,high price competitiveness,

reliable performance. -- 10.4 inch color display, lots of language can be chosen.

2. Speed and amplitude can be adjusted in operation process.

3. Adopt with high sensitivity sensor of roll film transfer system, ensure the machine can make the nice bag shape.

4. Whole bag former is made as one unit. The filn can running smoothly and prevent the damage.

5. Independent temperature control system, make the bag sealing clean.

Applications:

Suitable for puffed food, roasted nuts & seeds, potato chips, candy, sweet dumplings, biscuits,

pasta, herbal pieces, pet food, frozen food, hardware ect

Whole machine main including 4 parts:

1) Z type bucket elevator

2) Multihead weigher

3) Working platform

4) Main packing machine

5) Finished product conveyor

Technical Parameters:

Model	BS-420G
Film width	Max.420mm
Film thickness	0.03-0.1mm
Bag width	50-200 mm
Bag length	50-300 mm
Packing speed	10-70 bags/ min
Type of sealing	Pillow bag,3 or 4 side seal and gusset bag
Packing material	OPP/CPP, OPP/CE,PET/PE etc.
Air consumption	0.65 mpa
Gas consumption	0.3 cubic meter/ min
Machine dimensions	108013001400 mm
Machine weight	600 kg
Multi-weigher
Weighting and filling system	Head weighers
Weighting range	10-3000g (Different product have different weighting range )
Accuracy:	Bias:+-0.5g
Filling speed:	65bags/min
Hoper volume	1.6/2.5L/5L
Total power:	1.0kw
Weight	380KG

Tag:

Place of Origin:	Guangdong, China
Brand Name:	BOSHI
Certification:	CE SGS
Model Number:	BS-420 BS-520 BS-720

Minimum Order Quantity:	One sets
Price:	5000USD-18500USD per set
Packaging Details:	Standard three plywood wooden cases
Delivery Time:	10-15 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	300 sets per year

Dried Mango Corn Flakes Snack Packing Machine Automatic Multifunctional

Dried Mango Snack Packing Machine
