| Place of Origin: | China |
|---|---|
| Brand Name: | BOSHI Powder packing machine |
| Certification: | CE, ROSH, SGS |
| Model Number: | BS-420P BS-520P BS-720P |
| Minimum Order Quantity: | 1set |
| Price: | 8800-10800 USD |
| Packaging Details: | 3 plywood wooden box packaging |
| Delivery Time: | 15-30 working days |
| Supply Ability: | 50 sets/ month |
| Machine Name: | Powder Packing Machinery | Machine Parts :: | Powder Feeding Machine ,auger Filler, Packing Machine |
|---|---|---|---|
| Bag Type :: | Pillow Bag ,etc. | Machine Speed Range:: | 5-60 Bags/ Min |
| Bag Width:: | 50-200 Mm | Bag Length:: | 50-300 Mm |
| Driven Type:: | PneumaticPillow Bag Or Gusset Bag Or Quad Side Seal | Voltage:: | 220/380v |
| Dimension(L*W*H):: | L 1320 * W 920 * H 1392 Mm | ||
| High Light: | Pillow Bag Powder Packing Machine,Gusset Bag Powder Packing Machine |
||
1. Suitable for multi bags , such as gusset bag, pillow bag, hole punch bag etc.
2. Full auto from bag form, fill, seal, cut .
3. Auger scale filling system for filling with high accuracy grams.
4. Intelligent temperature controller suitable for many films .
5. Can equip metail detector, check weigher .
6. Weighting systems is auger filler.
|
Model
|
BS-420P |
|
Film width
|
Max.420mm |
| Film thickness | 0.03-0.1mm |
| Bag width | 50-200 mm |
| Bag length | 50-300 mm |
| Packing speed | 10-70 bags/ min |
| Type of sealing | Pillow bag,3 or 4 side seal and gusset bag |
| Packing material | OPP/CPP, OPP/CE,PET/PE etc. |
| Air consumption | 0.65 mpa |
| Gas consumption | 0.3 cubic meter/ min |
| Machine dimensions | 1080*1300*1400 mm |
| Machine weight | 600 kg |
| Auger filler | |
| Weighting and filling system | Auger screw |
| Weighting range | 10-5000g (Different product have different weighting range ) |
| Accuracy: | Volume<100g.Bias:0.5-1gVolume:100-5000g.Bias:0.5%-1% |
| Filling speed: | 10-60 bags/min |
| Filler hoper volume | 50 L |
| Total power: | 1.5 kw |
| Weight |
200KG
|
Machine advantages:
Applications:
Suitable for filling and packing varieties of powders, such as milk powder, coffee powder, fruit powder,cocoa powder, grain powder, wheat flour, spice, flour,and etc.
