| Place of Origin: | China |
|---|---|
| Brand Name: | BOSHI Powder packing machine |
| Certification: | CE, ROSH, SGS |
| Model Number: | BS-420P BS-520P |
| Minimum Order Quantity: | 1set |
| Price: | 8800-10800 USD |
| Packaging Details: | 3 plywood wooden box packaging |
| Delivery Time: | 15-30 working days |
| Supply Ability: | 50 sets/ month |
| Function:: | Filling, Wrapping, Labeling, Sealing, Date Printing | Film Materils :: | Laminated Film Roll |
|---|---|---|---|
| Bag Types :: | Gusset Bag Etc. | Machine Speed Range:: | 5-60 Bags/ Min |
| Bag Width:: | 50-200 Mm | Bag Length:: | 50-300 Mm |
| Driven Type:: | PneumaticPillow Bag Or Gusset Bag Or Quad Side Seal | Voltage:: | 220/380v |
| Dimension(L*W*H):: | L 1320 * W 920 * H 1392 Mm | ||
| High Light: | Chilli Powder Packing Machine,Filling Soap Powder Packing Machine |
||
1. PLC computer control system. PLC from Japan or Germany.
2. Bigger touch screen. Easy to operate and control the machine.
3. Servo motor from famous brand to ensure stable.
4. Alarm function, it helps to handle the trouble immediately.
5. Automatically measuring, feeding, filling, printing, sealing bag.
6. Making pillow bag and 3side seal bag . Punching hole bag and connect 5-12bags and so on .
|
Model
|
BS-420P |
|
Film width
|
Max.420mm |
| Film thickness | 0.03-0.1mm |
| Bag width | 50-200 mm |
| Bag length | 50-300 mm |
| Packing speed | 10-70 bags/ min |
| Type of sealing | Pillow bag,3 or 4 side seal and gusset bag |
| Packing material | OPP/CPP, OPP/CE,PET/PE etc. |
| Air consumption | 0.65 mpa |
| Gas consumption | 0.3 cubic meter/ min |
| Machine dimensions | 1080*1300*1400 mm |
| Machine weight | 600 kg |
| Auger filler | |
| Weighting and filling system | Auger screw |
| Weighting range | 10-5000g (Different product have different weighting range ) |
| Accuracy: | Volume<100g.Bias:0.5-1gVolume:100-5000g.Bias:0.5%-1% |
| Filling speed: | 10-60 bags/min |
| Filler hoper volume | 50 L |
| Total power: | 1.5 kw |
| Weight |
200KG
|
Machine advantages:
Applications:
Suitable for filling and packing varieties of powders, such as milk powder, coffee powder, fruit powder,cocoa powder, grain powder, wheat flour, spice, flour,and etc.
